Narrow Axed Motorcycle Gas Tank
With this tank, we narrowed up the axed gas tank just a little bit. It’s a subtle difference but provides a nice skinny look. This tank has a low tunnel, petcock bung on the left side and Harley Davidson cam style filler offset to the right.
Features:
- Low tunnel
- Single 1/4" NPT petcock bung at the back
- Requires vented H-D cam style gas cap - Throttle Addiction part numbers 1010 chrome, 1109 black.
Dimensions:
- 1.9 gal
- 8.5" wide x 15.25" long x 9" tall
- 17.5" long tab to tab
- Tunnel 2.5" wide x 2.8" deep
Disclaimer:
Tanks are pressure tested at the factory, but it is best to test again before you paint it. Be sure of fit of tank, mounting hardware, petcocks and gas caps are true prior to painting. No stress is applied to the tabs when bolting them to the frame, this can lead to cracking of welds. If needed, use leather or rubber washes to shim between the tabs and the backbone to ensure an even fit. Do not sand seams or welded edges of gas tanks, if needed use a thin spread of body filler prior to painting. Throttle Addiction warranties gas tank defects however we do not cover paint work. Ensure your tank arrived damage free BEFORE you paint!
